| Feature | Description |
|---|---|
| Power Specifications | Built-in power supply |
| Product Power Consumption | Operating: Approx. 27.8 W, Standby: Approx. 0.96 W |
| Supply Voltage | AC 100 to 230V / 50 to 60 Hz |
| Option | External buzzer unit |
| Print Font | 9 × 17 / 12 × 24, Hanji Font: 24 x 24, Thai Font: 9 x 24 / 12 x 24 |
| Characters Per Inch | 22.6cpi / 16.9cpi, Hanji Font: 7.8cpi, Thai Font: 22.6cpi / 16.9cpi |
| Character Size (W x H) | 0.88 × 2.13 mm / 1.25 × 3 mm, Hanji font: 3 x 3 mm, Thai font: 0.88 x 3 mm / 1.25 x 3 mm |
| Character Set | 95 Alphanumeric, 18 set International, 128 × 43 pages (including Thai / Viet and user-defined page) |
| Hanzi | Simplified Chinese: GB18030-2000: 28,553 |
| Bar code | UPC-A, UPC-E, JAN13(EAN13), JAN8(EAN), CODE39, ITF, CODABAR(NW-7), CODE93, CODE128, GS1-128, GS1 DataBar |
| Two-dimensional code | PDF417, QRCode, MaxiCode, 2D GS1 DataBar, Composite Symbology |
| Data Buffer | 4KB or 45 bytes |
| Paper Width and Roll Diameter | 79.5 ± 0.5mm |
| Overall Dimensions (D x W x H) | 192 x 149 x 140 mm |
| Printing Method | Thermal Line Printing |
| Standard Accessories | Roll paper × 1 roll (for checking the initial movement of the printer), Setup guide |
| Dot Density | 203 x 203 dpi |
| Mass | Approx. 1.5kg |
| Interfaces (Ethernet) | Yes, Ethernet Interface |
| Reliability (MTBF) | 360,000 hours |
| Reliability (MCBF) | 60,000,000 lines |
| Printer Mechanism Life | 15 million lines |
| Auto Cutter Life | 1.5 million cuts |
